Clinical Consumables

Cuffs and Fixation Rings

A Cuff for Every Purpose

To achieve accurate blood pressure measurements, it is important to occlude the blood flow completely and in a controlled manner. Because both width and length of digits and limbs vary, it is necessary to utilize different cuffs for different patients. Perimed supplies a wide range of pressure cuffs suitable for arm-, ankle- and toe-pressure measurements on most patients.

Perimeds pressure cuffs are equipped with bayonette fittings. If your system has pressure tubes featuring Luer connections the Cuff Adapter Kit for PF 5000 (Luer to Bayonet) is needed for all pressure tube outlets.

New Bayonet Connectors

CUFFS

All Cuffs and Hoses

Part number
Name
93-00234 Digit Cuff (XS) 1 cm Discontinued
 93-00235 UDC1.6 1.6 x 9 cm Digit Vascular Cuff
93-00236 UDC1.9 1.9 x 9 cm Digit Vascular Cuff
93-00237 UDC2.5 2.5 x 9 cm Digit Vascular Cuff
93-00238 UPC2.5 2.5 x 12 cm Digit Vascular Cuff
93-00239 UDCXXS 2.5 x 14 cm Custom Digit Vascular Cuff
93-00240 Digit Cuff (XL) 3.3 cm Discontinued
93-00241 TMC7 7 x 40 cm Vascular Cuff
93-00242 SC10 10 x 85 cm Straight Vascular Cuff
93-00243 SC12 12 x 85 cm Straight Vascular Cuff
93-00244 SC12L 12 x 124 cm Straight Vascular Cuff – Long version
93-00245 CC17 17 x 108 cm Contoured Vascular Cuff
93-00246 CC22 22 x 122 cm Contoured Vascular Cuff
 93-00186 PF 6051 Pressure Accessory Kit

FIXATION RINGS

TC 550 / TC 555 Fixation Rings

 TC 555 Fixation Rings

Perimed has developed fixation rings to facilitate the attachment of E5250 (tcpO2) and E5280 (tcpO2/tcpCO2) electrodes to the skin when monitoring transcutaneous oxygen/carbon dioxide. The rings have a small base diameter allowing for fixation to fingers, toes or other curvatures without risking leakage problems. TC 555 Fixation Ring Extra Strength has a special glue for better adhesion on patients with “problematic” skin. Fixation rings are delivered in kits together with TC 560 Contact Liquid.

Part number Product name
90-00054 TC 555 Fixation Ring for tcpO2 – Extra Strength Adhesive (50 pcs) and TC 560 Contact Liquid (20 ml)
90-00036 TC 560 Contact Liquid (20 ml)

Please fill in the form to get more information

Disclaimer: It is possible that the products on the Perimed website may not be cleared for sale in all markets.
